TFT XXL Mid-Ship Fuel Tanks

Transform your driving experience with the Titan 60 Gallon Extra Capacity Mid-Ship Replacement Fuel Tank, designed specifically for 2020-2026 GM 2500 and 3500 pickups with Crew Cabs, Long Beds, and Duramax engines. With this innovative upgrade, you're not just investing in a larger fuel tank - you're investing in unparalleled freedom and convenience on the road. Picture this: no more frequent stops at the gas station, no more worries about running out of fuel on long journeys, and no more compromises on where you can go or what you can do. With the Titan 60 Gallon tank, you have the power to stay on the road longer, tackle more ambitious projects, and explore farther than ever before. Whether you're towing heavy loads, embarking on cross-country adventures, or simply navigating daily commutes, the extra capacity provided by a Titan XXL Tank gives you the confidence and peace of mind to go the distance, no matter where the road takes you. Crafted from our renowned military-grade, cross-linked polymer material, this tank sets the standard for durability and reliability. With a thickness of at least 1/4", it's built to outlast all competitors, standing strong against the toughest conditions. Backed by a lifetime warranty, you can trust in its quality and performance for the long haul. The tank comes complete with a black-coated, galvanized steel mounting strap and front support system. Plus, with its exclusive low fuel trap design all 60 gallons are usable capacity. We could advertise a larger capacity, but we chose to only market usable capacity to set honest and reasonable expectations for our customers. The Titan XXL tank also features minimal hang down below the bottom of the stock tank (approximately only 2" lower). Application. For model years 2020-2026.For 2500HD and 3500HD Models with Duramax Engines.

The TITAN tank is 24 gallons larger at 60 gallons. The stock tank is only 36 gallons. Hellwig aftermarket rear sway bar #7782 is not compatible with this tank. Will not interfere with powered steps, air bag systems and most other accessories. Our mid-ship, direct replacement fuel tanks are designed to use your trucks' stock/OE sending unit. However, our tanks are compatible with Fleece, AirDog, FASS, etc. Technical Service Bulletin. Affected vehicles: 2019+ GM 6.6L diesel trucks. Issue: Fuel gauge drops to empty after Initial Install and during normal operation. Explanation: GM trucks have the ability through programming and monitoring to know exactly how much fuel is in the tank, as well as fuel consumption based on miles driven and fuel economy. Any large capacity fuel tank causes the float to move slower than the computer thinks is acceptable. When the computer sees this, it will run a system check and drop the fuel gauge to empty. When the fuel level comes off full, the gauge should return to the correction position after restarting the vehicle. Solution: Although we were told early on that trucks have fixed themselves after several tanks of fuel when following a specific process, we are no longer able to confirm this or any other permanent fix for this issue. If this is a concern for you, we recommend using an aftermarket digital monitor to confirm accurate fuel level when this occurs.

60 Gallon, extra capacity, extra heavy-duty mid-ship, replacement tank for the ultimate in fuel range. Tank comes complete with black coated, galvanized or stainless steel, mounting straps. Tapered tank features exclusive low fuel trap design so most every gallon can be used, and is approximately only 2 in. deeper than the stock OEM tank. Very similar in appearance to original equipment tank. TITAN's Generation 6 tanks feature the TITAN Torque Ring(TM) OEM style sending unit mounting system for easy, positive installation. At rated highway MPG++, this tank gives a GMC 2500 a range of over 1100 miles! This new Chevrolet/GMC tank is made of our famous military grade, cross-linked polymer (XLHDPE). It's at least ¼ in. thick and built to outlast all competitors. It's tougher than steel and more durable than aluminum. Like all fine TITAN(TM) products, this new design has undergone extensive testing. Our legendary products are so tough and well-proven that we back them with a Lifetime Warranty!. No cutting, drilling or fabrication required for installation.

Titan Fuel Tanks 20-24 GM 2500/3500 Duramax Crew Cab Long Bed 60 Gallon XXL Mid-Ship Fuel Tank

Titan Fuel Tanks 20-24 GM 2500/3500 60 Gal. Extra HD XXL Mid-Ship Tank - Crew Cab LB

Super Durable Military Grade Polymer, Cross-Linked Polyethylene (XLHDPE)

Nearly 200 Times Less Heat And Cold Conductive Than Metal Tanks

60 Gallon extra heavy duty, cross-linked polyethylene fuel tank

Nearly 200 Times Less Heat & Cold conductive than Metal Tanks

No Condensation, No Corrosion, and Easy to Install

No Condensation/No Corrosion And Easy To Install

Exclusive TITAN Sending Unit Mounting System

XXL Replacement Mid-Ship Fuel Tank 60 Gallon

Extra Large Midship Tank; 60 Gallon;

Super Durable Military Grade Polymer

Compatible With Most Bio-Diesel Fuel

Cross-Linked Polyethylene (XLHDPE)

TITAN XXL Replacement Tank 7010320

Extra Large Midship Tank

Fuel Tank
